Specifications SiBE12-712C
46 Specifications
50Hz 220-230-240V
Note:
1. The data are based on the conditions shown in the table below.
Model
2AMX40FV1B
Cooling Heating
Capacity kW —
Power Consumption W —
Running Current A —
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 1YC23ABXD
Motor Output W 600
Refrigerant Oil
Model FVC50K
Charge L 0.45
Refrigerant
Type R-410A
Charge kg 1.20
Airflow Rate
m³/min
H36 32
M33 32
L30 32
cfm
H 1,271 1,130
M 1,165 1,130
L 1,057 1,130
Fan
Type Propeller
Motor Output W 50
Starting Current A 5.9
Dimension (H
×
W
×
D) mm 550
×
765
×
285
Packaged Dimension (H
×
W
×
D) mm 612
×
906
×
364
Weight kg 38
Gross Weight kg 43
Operation
Sound
(Sound Pressure) dBA 47 48
Sound Power dBA 62 —
Piping
Connection
Liquid mm
φ
6.4
×
2
Gas mm
φ
9.5
×
2
Drain mm
φ
18
Heat Insulation Both Liquid & Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring
Max. Piping Length m
30 (for Total of Each Room)
20 (for One Room)
Min. Piping Length m 3 (for One Room)
Amount of Additional Charge g/m 20 (20m or more)
Max. Installation Height Difference m
15 (between Indoor Unit and Outdoor Unit)
7.5 (between Indoor Units)
Drawing No. 3D055823A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
5m
