Specifications SiBE12-712C
36 Specifications
50Hz 220-230-240V
Model
ATXG25EV1B ATXG35EV1B
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color Mat Crystal White Mat Crystal White
Airflow Rates
m³/min
(cfm)
H 7.7 (271) 9.0 (317) 8.1 (285) 9.6 (338)
M 6.1 (215) 7.9 (278) 6.5 (229) 8.2 (289)
L 4.7 (165) 6.7 (236) 4.9 (173) 6.7 (236)
SL 3.8 (134) 5.4 (190) 4.1 (144) 5.9 (208)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13
Power Consumption (Rated) W 30 30 30 30
Power Factor % 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 275×840×150 275×840×150
Packaged Dimensions (H×W×D) mm 222×894×345 222×894×345
Weight kg 9 9
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/33/28/25 39/33/26/23 39/34/29/26
Sound Power H dBA 56 56 57 57
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051107 3D051108
Model
ATXG50EV1B
Cooling Heating
Rated Capacity 5.0kW Class
Front Panel Color Mat Crystal White
Airflow Rates
m³/min
(cfm)
H 11.3 (398) 12.6 (444)
M 9.1 (320) 10.6 (373)
L 7.1 (250) 8.7 (306)
SL 6.7 (236) 7.7 (271)
Fan
Type Cross Flow Fan
Motor Output W 40
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof
Running Current (Rated) A 0.15-0.14-0.13 0.15-0.14-0.13
Power Consumption (Rated) W 30 30
Power Factor % 90.9-93.2-96.2 90.9-93.2-96.2
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 275×840×150
Packaged Dimensions (H×W×D) mm 222×894×345
Weight kg 9
Gross Weight kg 13
Operation
Sound
H/M/L/SL dBA 47/41/35/32 47/41/35/32
Sound Power H dBA 64 64
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
Gas mm
φ
12.7
Drain mm
φ
18.0
Drawing No. 3D051109
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
