Specifications SiBE12-712C
20 Specifications
50Hz 230V
Model FTKS20CAVMB FTKS25CAVMB
Rated Capacity 2.0kW Class 2.5kW Class
Front Panel Color White White
Airflow Rates
m³/min
(cfm)
H 7.7 (272) 7.7 (272)
M 5.9 (208) 5.9 (208)
L 4.2 (148) 4.2 (148)
SL 3.6 (127) 3.6 (127)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimensions (H×W×D) mm 258×834×325 258×834×325
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/32/25/22
Sound Power H dBA 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D050947 3D050949
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model FTKS35CAVMB
Rated Capacity 3.5kW Class
Front Panel Color White
Airflow Rates
m³/min
(cfm)
H 7.7 (272)
M 6.0 (212)
L 4.4 (155)
SL 3.8 (134)
Fan
Type Cross Flow Fan
Motor Output W 18
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18
Power Consumption (Rated) W 40
Power Factor % 96.6
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195
Packaged Dimensions (H×W×D) mm 258×834×325
Weight kg 7.5
Gross Weight kg 11
Operation
Sound
H/M/L/SL dBA 39/33/26/23
Sound Power H dBA 57
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid
mm
φ
6.4
Gas
mm
φ
9.5
Drain
mm
φ
18.0
Drawing No. 3D050951
