SiBE12-712C Troubleshooting
Service Diagnosis 221
4.11 Input Over Current Detection
Remote
Controller
Display
E8
Method of
Malfunction
Detection
An input over-current is detected by checking the power consumption value of outdoor unit with
the compressor running.
Malfunction
Decision
Conditions
The following input value (calculated from power consumption of outdoor unit) with the
compressor running continues for 2.5 seconds.
Input value : Above 15 A
Supposed
Causes
Over-current due to compressor failure
Over-current due to defective power transistor
Over-current due to defective inverter main circuit electrolytic capacitor
Over-current due to defective outdoor unit PCB
Error detection due to outdoor unit PCB
Over-current due to short-circuit
