Specifications SiBE12-712C
30 Specifications
50Hz 220-230-240V
Note:
1. The data are based on the conditions shown in the table below.
Model 2AMK50FV1B
Cooling Capacity kW
—
Power Consumption W
—
Running Current A
—
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC36BXD
Motor Output W 1,100
Refrigerant Oil
Model FVC50K
Charge L 0.65
Refrigerant
Type R-410A
Charge kg 1.60
Airflow Rates
m³/min
HH 37
H34
L34
cfm
HH 1,303
H 1,214
L 1,214
Fan
Type Propeller
Motor Output W 50
Starting Current A 9.8
Dimensions (H×W×D) mm 550×765×285
Packaged Dimensions (H×W×D) mm 612×906×362
Weight kg 42
Gross Weight kg 47
Operation
Sound
HH dBA 48
LdBA 44
Sound Power dBA 63
Piping Connection
Liquid mm
φ
6.4
×
2
Gas mm
φ
9.5
×
1,
φ
12.7
×
1
Drain mm
φ
18.0
Heat Insulation Both Liquid and Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length
m 30 (for Total of Each Room)
m 20 (for One Room)
Min. Interunit Piping Length m 3 (for One Room)
Amount of Additional Charge g/m 20 (20m or more)
Max. Installation Height Difference
m 15 (between Indoor Unit and Outdoor Unit)
m 7.5 (between Indoor Units)
Drawing No. 3D057677
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB
5m
