SiBE12-712C Specifications
Specifications 21
50Hz 230V
Model ATKS20E2V1B ATKS25E2V1B
Rated Capacity 2.0kW Class 2.5kW Class
Front Panel Color White White
Airflow Rates
m³/min
(cfm)
H 8.7 (307) 8.7 (307)
M 6.7 (237) 6.7 (237)
L 4.7 (166) 4.7 (166)
SL 3.9 (138) 3.9 (138)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.16 0.16
Power Consumption (Rated) W 35 35
Power Factor % 95.1 95.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/32/25/22
Sound Power H dBA 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051743 3D051744
Model ATKS35E2V1B ATKS20DAVMB
Rated Capacity 3.5kW Class 2.0kW Class
Front Panel Color White White
Airflow Rates
m³/min
(cfm)
H 8.9 (314) 7.7 (272)
M 6.9 (244) 5.9 (208)
L 4.8 (169) 4.2 (148)
SL 4.0 (141) 3.6 (127)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 18
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 273×784×195
Packaged Dimensions (H×W×D) mm 265×855×340 258×834×325
Weight kg 9 7.5
Gross Weight kg 12 11
Operation
Sound
H/M/L/SL dBA 39/33/26/23 38/32/25/22
Sound Power H dBA 57 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051745 3D050959
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
