Fagor 2V-33TS [15/62] Instruction manual
![Fagor 2V-33TS [15/62] Instruction manual](/views2/1078156/page15/bgf.png)
english
13
220-240V 3~ Nominal switch by phases
60 cm hob 14 A
>60cm hob 16,5 A
380-415V 3N~ Nominal switch by phases
60 cm hob 11 A
>60cm hob 13 A
380-415V 2N~ Nominal switch by phases
60 cm hob 16 A
>60cm hob 19 A
This appliance is compliant with European
directives 73/23/EEC and 89/336/EEC
Recommendation: The hob must be installed
by an authorised installer, who shall follow the
manufacturer’s instructions and diagrams.
1
Instruction Manual
Very important: Read this manual thoroughly before using the hob.
This manual is designed so that the texts relate to the corresponding illustrations.
2
Installation
Use
Identify the model of your hob (“a”, “b”, “c”,
“d”, “e”, “f”, “g”, “h”, “i”, “j”, “k”, “l”, “m”, “n”,
“o”) by comparing the number and layout of the
elements on your appliance with that shown in
the illustrations.
1.1 Unpacking. Remove all the protective
materials.
1.2 Insertion into the unit. Always take into
account the details on the characteristics
plate (1.2.1) and the measurements of
the unit into which the hob is going to be
inserted (1.2.2, 1.2.3). If you are not going
to fi t an oven beneath the hob, you must
install a protective panel in accordance with
the measure indicated (1.2.4). Stick the foam
join along the outer edge of the hob to make
it watertight (1.2.5). Turn the hob over and
insert it into the hole (1.2.6). Secure it to the
unit with the four hooks supplied (1.2.7). Do
not use non-removable materials such as
silicone.
1.3 Connection to the power supply. The hob
is supplied with a power cable.
• With 5 wires: a) dark blue, b) light blue, c)
brown, d) red, e) green yellow. (1.3.1)
• Prepared for a 230V~ hob. (1.3.2)
• Prepared for a 220-240V~ hob: see table.
(1.3.3)
• Total power: 60cm hob 6.8kW,
>60cm hob 7.8kW
220-240V~ Nominal switch by phases
60 cm hob 30 A
>60cm hob 34 A
• If the type of connection is other than 220-
240V~, remove the cable and make the
connection as per diagrams (1.3.3, 1.3.4).
0
Identifi cation
Clay, copper or stainless steel receptacles can
be used with vitroceramic hobs. Aluminium
receptacles are not recommended as they can
stain the glass of the hob.
2.1 Selecting the cooking zone. You have
various elements on which to place the
receptacles. Choose the most suitable one
depending on the size of the receptacle.
2.2 Turning on the hob. Press
for 3
seconds to turn on the hob; the
0
of the
different cooking zones will be activated.
N.B.: In order to be able to select whether
the child safety function is activated,
deactivate it by pressing the
key for 3
seconds (2.13)
2.3 Activating the element. Activate the
element on which you have placed the
receptacle by pressing the corresponding
key
(2.3.1, 2.3.2). or
press
(2.4.2)
N.B.: If you take longer than 5 seconds to
select the element, the hob will automatically
turn itself off, as a safety measure.
