Field Setting ESIE09-08B
90 Test Operation
[1] Automatic storage timing for domestic water heating
In this mode, the indoor unit will deliver hot water to the domestic hot water tank based on the
daily fixed pattern. This mode will continue until storage temperature is reached, no times are
involved.
Automatic storage is the advised domestic hot water mode. In this mode water heats up during
the night (when space heating requ
irements are lower) until the storage set point. The heated
water is stored in the domestic hot water tank at a higher temperature so it can fulfil the
domestic hot water requirements throughout the day.
The storage temperature set point and timing are field settings.
[1-00] Status: defines whether the do
mestic water heating (storage mode) d
uring night is
enabled (1) or not (0).
[1-01] Start time: time of the night at which the domestic water should be heated. The ending
time will variate for each sy
stem.
[1-02] Status: defines whether the domestic water heating (storage mode) during daytime is
enabled (1) or not (0).
[1-03]
Start time: time of the day at which the domestic water should be heated. The ending
time will variate for each sy
stem.
Notes : 1. Make sure the domestic hot water is only heated up to the domestic hot water temperature
you require.
Start with a low domestic hot water storage temperature set point, and only increase if you
feel that the domestic hot water supply temperature is not sufficient for your needs (this
depend
s on your water using pattern).
2. Make sure the domestic hot water is not heated unnecessary. Start with activating automatic
storage during night (default setting). If it seems that the do
mestic hot wa
ter night storage
operation is not sufficient for your needs, an additional storage during daytime can be set.
3. For energy-saving purposes, it is advised to enable the weather dependent domestic water
heating. Refer to setting “[b-02] Status: defines whether the weather dependent domestic
water heating is turned ON (1) or OFF (0).” on page 102.
4. Manual storage is possible: to activate push 5 seconds on the w button. The w icon
starts
to blink, the water w
ill be heated up till storage set point (one time action). It can also be
stopped manually by pushing the w button.
5. Be aware that despite the automatic storage is a pre-programmed schedule timer, it is only
active when the schedule timer is enabled. This means that you
have to push the rp
button
and confirm that the p is displayed to make sure that the automatic storage will operate.
Refer to "[b] Domestic hot water set points" for temperature set points.
First
code
Second
code Setting name
Default
value Range Step Unit
1 Automatic storage timing for domestic water heating
00 Status: night time storage 1 (ON) 0/1 — —
01 Night time storage start time 1:00 0:00~23:00 1:00 hour
02 Status: day time storage 0
(OFF)
0/1 — —
03 Day time
storage start time 15:00 0:00~23:00 1:00 hour
