![Daikin EKHTSU260AC [230/292] Indoor unit](/img/pdf.png)
Daikin EKHTSU260AC [230/292] Indoor unit
![Daikin EKHTSU260AB [230/292] Indoor unit](/views2/1797983/page230/bge6.png)
Piping Diagrams ESIE09-08B
218 Appendix
2.2 Indoor Unit
EKHBRD 011~016 AA/ABV1/Y1
FILTER FILTER
FILTER FILTER
FILTER
DRAIN VALVE
BLOW
OFF
SAFETY
VALVE
PRESSURE
GAUGE
EXPANSION
VESSEL
WATER INLET
OPTION DOMESTIC HOT
WATER TANK
PLATE
HEAT
EX-
CHANGER
R-134a
PLATE HEAT
EXCHANGER
R-410A /
R-134a
CHECK
VALVE
M1C
E1HC
R6T
Y1R
M
K1S
R5T
Q2L
R4T
M1P
K2S
K1E
K2E
R3T
R7T
B1PL
B1PH
S1PH
ACCUMULATOR
CHECK
VALVE
*KHTS*
200~260*
G 1”1/4 (female)
WATER OUTLET
STANDARD
WATER SIDE
3-WAY
VALVE
REFRIGERANT SIDE
OUTDOOR UNIT
SERVICE PORT
5/16”
SERVICE PORT
5/16”
*R*Q011~016**
FIELD INSTALLATION
(DELIVERED WITH
OPTION DOMESTIC
HOT WATER TANK)
G 1”1/4 (female)
AIR
PURGE
SHUT OFF
VALVE
SHUT OFF
VALVE
FIELD PIPING ø15.9 C 1220T-0
FIELD PIPING ø9.5 C 1220T-0
SV
HEATING
DEFROST
1 1
1
