Thermistor Resistance / Temperature Characteristics ESIE09-08B
240 Appendix
Outdoor Unit
Thermistors for
Discharge Pipe
(R2T)
(k)
T°C 0.0 0.5 T°C 0.0 0.5 T°C 0.0 0.5
0 640.44 624.65 50 72.32 70.96 100 13.35 13.15
1 609.31 594.43 51 69.64 68.34 101 12.95 12.76
2 579.96 565.78 52 67.06 65.82 102 12.57 12.38
3 552.00 538.63 53 64.60 63.41 103 12.20 12.01
4 525.63 512.97 54 62.24 61.09 104 11.84 11.66
5 500.66 488.67 55 59.97 58.87 105 11.49 11.32
6 477.01 465.65 56 57.80 56.75 106 11.15 10.99
7 454.60 443.84 57 55.72 54.70 107 10.83 10.67
8 433.37 423.17 58 53.72 52.84 108 10.52 10.36
9 413.24 403.57 59 51.98 50.96 109 10.21 10.06
10 394.16 384.98 60 49.96 49.06 110 9.92 9.78
11 376.05 367.35 61 48.19 47.33 111 9.64 9.50
12 358.88 350.62 62 46.49 45.67 112 9.36 9.23
13 342.58 334.74 63 44.86
44.07 113 9.10 8.97
14 327.10 319.66 64 43.30 42.54 114 8.84 8.71
15 312.41 305.33 65 41.79 41.06 115 8.59 8.47
16 298.45 291.73 66 40.35 39.65 116 8.35 8.23
17 285.18 278.80 67 38.96 38.29 117 8.12 8.01
18 272.58 266.51 68 37.63 36.98 118 7.89 7.78
19 260.60 254.72 69 36.34 35.72 119 7.68 7.57
20 249.00 243.61 70 35.11 34.51 120 7.47 7.36
21 238.36 233.14 71 33.92 33.35 121 7.26 7.16
22 228.05 223.08 72 32.78 32.23 122 7.06 6.97
23 218.24 213.51 73 31.69 31.15 123 6.87 6.78
24 208.90 204.39 74 30.63 30.12 124 6.69 6.59
25 200.00 195.71 75 29.61 29.12 125 6.51 6.42
26 191.53 187.44 76 28.64 28.16 126 6.33 6.25
27 183.46 179.57 77 27.69 27.24 127 6.16 6.08
28 175.77 172.06 78
26.79 26.35 128 6.00 5.92
29 168.44 164.90 79 25.91 25.49 129 5.84 5.76
30 161.45 158.08 80 25.07 24.66 130 5.69 5.61
31 154.79 151.57 81 24.26 23.87 131 5.54 5.46
32 148.43 145.37 82 23.48 23.10 132 5.39 5.32
33 142.37 139.44 83 22.73 22.36 133 5.25 5.18
34 136.59 133.79 84 22.01 21.65 134 5.12 5.05
35 131.06 128.39 85 21.31 20.97 135 4.98 4.92
36 125.79 123.24 86 20.63 20.31 136 4.86 4.79
37 120.76 118.32 87 19.98 19.67 137 4.73 4.67
38 115.95 113.62 88 19.36 19.05 138 4.61 4.55
39 111.35 109.13 89 18.75 18.46 139 4.49 4.44
40 106.96 104.84 90 18.17 17.89 140 4.38 4.32
41 102.76 100.73 91 17.61 17.34 141 4.27 4.22
42 98.75 96.81 92 17.07 16.80 142 4.16 4.11
43 94.92 93.06
93 16.54 16.29 143 4.06 4.01
44 91.25 89.47 94 16.04 15.79 144 3.96 3.91
45 87.74 86.04 95 15.55 15.31 145 3.86 3.81
46 84.38 82.75 96 15.08 14.85 146 3.76 3.72
47 81.16 79.61 97 14.62 14.40 147 3.67 3.62
48 78.09 76.60 98 14.18 13.97 148 3.58 3.54
49 75.14 73.71 99 13.76 13.55 149 3.49 3.45
50 72.32 70.96 100 13.35 13.15 150 3.41 3.37
