ESIE09-08B Switch Box Layout - Indoor Unit EKHBRD
Refrigerant Circuit 31
No. Partnumber Name
1 A1P Main PCB
2 A3P Control PCB
3 A5P Inverter PCB
4 A4P Inverter control PCB (only Y1)
5 A5P QA PCB (only V1)
6 A6P Filter PCB
7 A7P Digital I/O PCB (Optional)
8 A8P Demand PCB (Optional)
9 X1M Terminal block: Main power supply
10 X2M Terminal block: AC connections
11 X3M Terminal block: DC connections
12 X1Y DC connector (low voltage)
13 X2Y Pump connector
14 X3Y AC connectory
15 Cable tie mountings
16 Power wiring entry
17 AC field wiring entry
18 DC field wiring entry
19 Compressor cable entry
20 K1A Interface relay
21 Wiring bridges
22 Fuse F1 (Only Y1)
23 Fuse F2 (Only Y1)
