ESIE09-08B PCB Layout for EKHBRD 011/014/016 AA/AB/AC/AD V1/Y1
Refrigerant Circuit 33
*: A7P, A8P= option PCB; connection not standard
Connector Connected to Color
SS1 Emergency switch
X6A - Yellow
X7A K1E: electronic expansion valve White
X12A R4T: returning water thermistor Yellow
X15A - White
X16A - White
X17A R5T: leaving water thermistor Yellow
X18A R3T: liquid thermistor R-410A Red
X19A - White
X20A M1P: DC inverter pump White
X23A - Blue
X24A - Black
X25A - White
X27A X803A of PCB A5P Black
X30A X3M
[3; 4 -> F
1
F
2
]
[7; 8 -> P
1
P
2
]
White
X33A X2A of PCB A7P* White
X35A X10A of PCB A3P White
X36A - Red
X38A - White
X50A - White
X60A - Blue
X65A - White
X70A X15A of PCB A3P Yellow
X85A X80A of PCB A8P* White
