ESIE09-08B Functional Parts Layout
Refrigerant Circuit 25
Bottom view
Bird’s-eye view
Hot water out
Cold water in
Coil in (from EKHBRD)
Recirculation connection
Pressure relief connection
Coil out (towards EKHBRD)
Recirculation pipe
Recirculation connection
Hot water out connection
Pressure relief connection
Anode
Heat exchanger
Cold water in connection
Coil out connection towards EKHBRD
Hot water pipe
Coil in connection from EKHBRD
