Hitachi CJ14DSL [14/100] English

English

CUTTING

CAUTION

䡬 In order to prevent blade dislodging, damage or

excessive wear on the Plunger, please make sure to

have surface of the base plate attached to the work

piece while sawing.

䡬 At low speed do not cut a wood with a thickness of

more than 10 mm or metal with a thickness of more

than 1 mm.

1. Rectilinear cutting

When cutting on a straight line, first draw a marking

gauge line and advance the saw along that line. Using

the guide (sold separately) will make it possible to

cut accurately on a straight line.

(1) Loosen the base bolt hexagonal bar wrench attached

on base. (Fig. 15)

(2) Move the base fully forward (Fig. 16), and tighten the

base bolt again.

(3) Attach the guide by passing it through the attachment

hole on the base and tighten the M5 bolt. (Fig. 17)

(4) Set the orbital position to “0”.

NOTE:

To ensure accurate cutting when using the Guide (Fig.

17), always set the orbital position to “0”.

2. Sawing curved lines

When sawing a small circular arc, reduce the feeding

speed of the machine. If the machine is fed too fast, it

could cause the blade to break.

3. Cutting a circle or a circular arc

The guide also will be helpful for circular cutting.

After attaching the guide by same way noted as above,

drive the nail or screw into the material through the

hole on the guide, then use it for an axis when cutting.

(Fig. 18)

NOTE:

Circular cutting must be done with the blade

approximately vertical to the bottom surface of the

base.

4. Cutting metallic materials

(1) Set the orbital position to “0” or “I”.

(2) Cut the material at medium speed.

(3) Always use an appropriate cutting fluid (spindle oil,

soapy water, etc.). When a liquid cutting fluid is not

available, apply grease to the back surface of the

material to be cut.

5. Pocket cutting

(1) In lumber

Aligning the blade direction with the grain of the

wood, cut step by step until a window hole is cut in

the center of the lumber. (Fig. 19)

(2) In other materials

When cutting a window hole in materials other than

lumber, initially bore a hole with a drill or similar tool

from which to start cutting.

6. Angular cutting

The base can be swiveled to both sides by up to 45°

for angular cutting. (Fig. 20)

(1) Loosen the base bolt by hexagonal bar wrench

attached on base and move the base fully forward.

(Fig. 15, 16)

(2) Align the scale (from 0 degrees to 45 degrees by 15-

degree increments) of the semi-circular part of the

base with the [

] mark on the gear cover. (Fig. 21)

(3) Tighten the M5 bolt again. (Fig. 15)

(4) Set the orbital position to “0”.

NOTE:

Angular cutting can not be done when adopting chip

cover or dust collector.

CONNECTING WITH CLEANER

By connecting with cleaner (sold separately) through dust

collector (sold separately) and adapter (sold separately),

most of dust can be collected.

(1) Remove the hexagonal bar wrench from the base.

(2) Move the base fully forward. (Fig. 15, 16)

(3) Attach the chip cover.

(4) Connect the dust collector with adapter. (Fig. 22)

(5) Connect the adapter with the nose of cleaner. (Fig.

22)

(6) Insert dust collector into the rear hole of the base until

the hook catches in the notch. (Fig. 23)

(7) Press the hook to remove the dust collector.

NOTE:

Wear the dust mask additionally, if available.

CONCERNING CUTTING OF STAINLESS STEEL

PLATES

CAUTION

In order to prevent blade dislodging, damage or excessive

wear on the Plunger, please make sure to have surface

of the base plate attached to the work piece while sawing.

When cutting stainless steel plates, adjust the unit as

described below:

1. Adjust the speed

NOTE:

The higher the speed is, the quicker the material is

cut. But the service life of the blade will be reduced in

this case. When the speed is too low, cutting will take

longer, although the service life will be prolonged.

Make adjustments as desired.

2. Set the orbital position to “0”

NOTE:

䡬 When cutting use cutting fluid (oil base cutting fluid)

to prolong the blade’s service life.

SELECTION OF BLADES

䡬 Accessory blades

To ensure maximum operating efficiency and results,

it is very important to select the appropriate blade

best suited to the type and thickness of the material

to be cut. Three types of blades are provided as

standard accessories. The blade number is engraved

in the vicinity of the mounting portion of each blade.

Select appropriate blades by referring to Table 5.

HOUSING THE HEXAGONAL BAR WRENCH

It is possible to house the hexagonal bar wrench on the

base. (See Fig. 24)

Blade

Thickness of material

Speed

No. 97 1.5 – 2.5 mm

Middle speed

01Eng_CJ14DSL_EE 3/19/08, 13:4513
