õUNGHEINRICH Event Messages
03.1512
G
_1115Operation
Combination "brake
setpoint" against brake
pressure invalid (movement
without brake pressure)
The event message is triggered
if for T = 250 ms the following applies:
•V
brake pedal
> 80% and brake pressure < 40bar
-Check brake fluid level;
-Check proximity sensor;
-Check pressure sensors;
_1116Operation
Combination "brake
setpoint" against brake
pressure invalid (brake
pressure without movement)
The event message is triggered
if for T = 250 ms the following applies:
•V
brake pedal
< 20% (> 7 volt ) and brake pressure
>20bar
-Check brake fluid level;
-Check proximity sensor;
-Check pressure sensors;
_1117Operation
Sum of the voltages
"Braking 1 setpoint" to
"Braking 2 setpoint" invalid
The event message is triggered
if for T = 250 ms the following applies:
•V
brake pedal
1 + V
brake pedal
2 > 5.5V or
•V
brake pedal
1 + V
brake pedal
2 < 4.5V
-Check the cable connection;
-check accelerator-pedal power supply /
tiller head power supply;
-replace accelerator pedal / tiller arm;
-replace the controller that is evaluating the
signal;
_1121Operation
Travel setpoint and release
contact invalid
The event message is triggered if the following applies
for T = 250msec:
V
accelerator pedal
< 12.5% and
Logic signal release contact = 1
-Check wire connection;
-Check accelerator pedal/tiller arm power supply;
-Replace accelerator pedal / tiller arm;
-Replace signal-evaluating controller;
_1122Operation
Travel setpoint and release
contact invalid
The event message is triggered if the following applies
for T = 250msec:
V
accelerator pedal
> 25 % and
Logic signal release contact = 0
-Check wire connection;
-Check accelerator pedal/tiller arm power supply;
-Replace accelerator pedal / tiller arm;
-Replace signal-evaluating controller;
_1123Operation
Total voltage "Travel1
setpoint" to "Travel2
setpoint" invalid
The event message is triggered
if for T = 250 ms the following applies:
•V
brake pedal
1 + V
brake pedal
2 > 5.5V or V
brake pedal
1 +
V
brake pedal
2 < 4.5V
-Check wire connection;
-Check accelerator pedal/tiller arm power supply;
-Replace accelerator pedal / tiller arm;
-Replace signal-evaluating controller;
F E XX SOperational
Status
DescriptionCause / Triggering EventAction
