Jungheinrich ERC 214 [181/214] Õungheinrich event messages

õUNGHEINRICH Event Messages

03.15181

_8012OperationCAN Bus faulty

Driver error from stack. Sub index means:

2: Driver switched to “passive”

The master has been informed via EMCY ID 8120 that

anode is reporting error "CAN in Error Passive Mode".

Events are entered with the node number of the

transmitting component

The function assembly used is the function assembly

ofthe transmitting component.

Events recognised by the master are entered with

nodenumber 1 and function assembly 0.

-Check the physical properties of the CAN Bus;

- Measure the CAN-Bus signal;

- Check CAN-Bus signals for frame leakage;

- Check equipotential bonding;

- Check terminal resistances (60 ±10%);

-Check CAN-Bus via JUDIT

(CAN-Bus load, ...);

-Bypass components connected to the CAN-Bus

in turn;

-Replace controller;

_8013OperationCAN Bus faulty

Driver error from stack. Sub index means:

3: Telegram buffer in CAN driver has overrun

The master has been informed via EMCY ID 8110 that

anode is reporting error "CAN overrun (objects lost)".

Events are entered with the node number of the

transmitting component

The function assembly used is the function assembly

ofthe transmitting component.

Events recognised by the master are entered with

nodenumber 1 and function assembly 0.

-Check CAN-Bus load via JUDIT;

-Check the physical properties of the CAN Bus;

- Measure the CAN-Bus signal;

- Check CAN-Bus signals for frame leakage;

- Check equipotential bonding;

- Check terminal resistances (60 ±10%);

-Bypass components connected to the CAN-Bus

in turn;

-Switch optional components off from CAN-Bus,

e.g. road traffic lighting.

-Replace controller;

_8014OperationCAN Bus faulty

Driver error from stack. Sub index means:

4: Receive buffer (Rx) has overrun (software)

Events are entered with the node number of the

transmitting component

The function assembly used is the function assembly

ofthe transmitting component.

Events recognised by the master are entered with

nodenumber 1 and function assembly 0.

-Check CAN-Bus load via JUDIT;

-Switch optional components off from CAN-Bus,

e.g. road traffic lighting.

F E XX SOperational

Status

Description Cause / Triggering Event Action
