õUNGHEINRICH Event Messages

03.15178

_7551OperationDistance travelled too great

UPC specific:

Excessive travel distance recorded

-Manually move the shuttle to the channel start,

remove any blockage (use recovery vehicle);

-Check drive chain.

The travel route in jog mode has exceeded the fixed or

parameterised distance

-Check the parameterised distance on the "jog

mode" option;

-Check wheels for wear (check wheel diameter)

NOTE:

Worn wheels will affect the travel distance

measured.

-Reference to function of jog mode setting

(option)

An operating error may have caused this.

_7561Operation

UPC specific:

Pallet positioning sensor

faulty

After the positive flank of 7B37.4 there is no positive

flank at 7B37.2

After the positive flank of 7B37.3 there is no positive

flank at 7B37.1

-Manually move the shuttle to the channel start

-Check pallet detection sensors 7B37.1-7B37.4

for contamination, incorrect settings and faults

-Check wire connection

_7571Operation

UPC specific:

Invalid travel setpoint

specification

Speed specification too high

-Manually move the shuttle to the channel start

-Repeat the travel command

_7581Operation

UPC specific:

Invalid shuttle position

Too many signal changes at 7B33.1 and 7B33.2

-Manually move the shuttle to the channel start

-Check rail hole sensors 7B33.1, 7B33.2 for

contamination, incorrect settings and faults

-Check wire connection

-Check number of rail holes

-Check rail holes and travel channel for

contamination

-Check the shuttle in a different travel channel.

F E XX SOperational

Status

DescriptionCause / Triggering EventAction
