õUNGHEINRICH Event Messages

03.158

_10612Operation

Logic test: signal at left/right

gate lock inputs improbable

During operation combinations 0/1 and 1/0 trigger the

event message. The activation limit is 2000 msec.

-Check wiring with multimeter;

-Test sensor system with multimeter;

-Check computer component inputs;

-Repair faulty components and replace if

necessary;

_10613Operation

Logic test: No signal for gate

lock despite gate lock being

applied

During operation no feedback triggers the message

when applied. The activation limit is 2000 msec.

-Check wiring with multimeter;

-Test sensor system with multimeter;

-Check computer component inputs;

-Repair faulty components and replace if

necessary;

_10614Operation

Logic test: Signal for gate

lock present despite gate

lock not being applied

During operation a feedback triggers the message

without being applied. The activation limit is 2000 msec.

-Check wiring with multimeter;

-Test sensor system with multimeter;

-Check computer component inputs;

-Repair faulty components and replace if

necessary;

_10615Operation

Logic test: No signal for gate

lock despite the lift

mechanism being above the

set height

During operation no feedback triggers the message

when lift mechanism is above the set height. The

activation limit is 2000 msec.

-Check wiring with multimeter;

-Test sensor system with multimeter;

-Check computer component inputs;

-Repair faulty components and replace if

necessary;

_1071Operation

Operator protection switch

inputs implausible

The body protection switch consists of a NC and a NO

contact. When the button is pressed both contacts

connect simultaneously. As a result, only the 0/1 and 1/0

combinations should occur.

During operation combinations 0/0 and 1/1 (500msec.)

trigger the event message.

For a valid combination (0/1 or 1/0, 500msec) the event

message and the truck response are reset.

-Check wire connections;

-Check operator protection switch;

-Replace operator protection switch;

F E XX SOperational

Status

DescriptionCause / Triggering EventAction
