Sub-division of event group “E”

Display system

The system distinguishes between:

•event messages caused by operator errors.

•event messages caused by truck errors.

For operator errors there are three versions that can be displayed

in the truck depending on the display unit options.

•Event number display (e.g. CANDIS)

•Pictogram display

•Text message display

For truck errors the event number and possibly a fault graphic icon

(e.g. service key) will also be displayed.

Trucks that only use one luminous display (e.g. LED) use the

following flashing code:

•Each character of the four-digit event number is shown with a

2 Hz / 0.5 sec frequency (flashing).

The figure “zero” is displayed by flashing ten times.

•After each character of the four-digit event message there is

a pause (LED off) of one second.

•After the complete four-digit event message a 3 second

pause (LED off) is set.

Fault reset or

no fault

General fault / additional functions

Example:

Logic error, e.g. both directions selected simultaneously

Current

(input interface, device-internal, output interface)

Voltage

(input interface, device-internal, output interface)

4Temperature

Hardware

Example: Output transformer short circuit, EEPROM not

responding, …

Software

(internal software, application software, data record /

parameters)

Example:

EEPROM data error

7Additional modules

8CAN monitoring

External fault

Example: ISM
