GEN
INFO
1-15
69R3J11
General information
4. Check the screwed length of the shift /
throttle cable joint 4 .
w
The shift / throttle cable joint 4 must be
screwed in a minimum of 8.0 mm (0.31 in)
b.
Checking the steering system
1. Check the steering friction for proper
adjustment.
NOTE:
9 To increase the friction, turn the friction
adjusting bolt in direction a.
9 To decrease the friction, turn the friction
adjusting bolt in direction b.
69R10065
b
4
2. Check that the steering operates smooth-
ly.
3. Check that there is no interference with
wires or hoses when the outboard motor
is steered.
6B410075
b
a
6S610050
69R10055
69R3J11_01 06.7.6 14:31 Page 18
