General specification
Item Unit
Model
E30HMH 30HMH 30HWH
Fuel and oil
Fuel type Regular unleaded gasoline
Engine oil 2-stroke outboard motor oil
Engine oil grade NMMA-certified TC-W3
Gear oil type Hypoid gear oil
Gear oil grade (*1) API GL-4
SAE 90
Gear oil quantity cm
3
(US oz, 320 (10.82, 11.29)
lmp oz)
Bracket unit
Trim angle Degree 4.0, 8.0, 12.0, 16.0, 20.0
(at 12° boat transom)
Tilt-up angle Degree 76.0
Steering angle Degree 40.0 + 40.0
Drive unit
Gear shift positions F-N-R
Gear ratio 2.08 (27/13)
Reduction gear type Spiral bevel gear
Clutch type Dog clutch
Propeller shaft type Spline
Propeller direction (rear view) Clockwise
Propeller ID mark F
Electrical
Battery minimum capacity (*2)
CCA/EN A — 347
20HR/IEC Ah — 40
(*1) Meeting both API and SAE requirements
(*2) CCA: Cold Cranking Ampere
EN: European Norm (European standard)
IEC: International Electrotechnical Commission
