Maintenance specification
Coil resistance and peak voltage are reference data.
Measuring conditions:
Ambient temperature 20°C (68°F).
Item Unit
Model
30HW 30HWC
CDI unit output peak voltage
(#1:B/O–B, #2:B/W–B)
at Cranking (loaded) V 130
at 1,500 r/min (loaded) V 135
at 3,500 r/min (loaded) V 135
Pulser coil output peak voltage
(W/R–B, W/B–B)
at Cranking (unloaded) V 6.8
at Cranking (loaded) V 6.7
at 1,500 r/min (loaded) V 16.0
at 3,500 r/min (loaded) V 26.0
Pulser coil resistance
(W/R–B, W/B–B) Ω 311–381
at 20°C (68°F)
Thermoswith
ON temperature °C (°F) 106–114 —
(222.8–237.2)
OFF temperature °C (°F) 88–102 —
(190.4–215.6)
Charge coil output peak
voltage (Br–L)
at Cranking (unloaded) V 146
at Cranking (loaded) V 146
at 1,500 r/min (loaded) V 150
at 3,500 r/min (loaded) V 150
Charge coil resistance (Br–L) Ω 342–418
at 20°C (68°F)
Starter motor
Type Bendix
Output kW 0.6
Brushes
Standard length mm (in) 12.5 (0.49)
Wear limit mm (in) 9.0 (0.35)
Commutator
Standard diameter mm (in) 30.0 (1.18)
Wear limit mm (in) 29.0 (1.14)
Standard undercut mm (in) 0.8 (0.03)
Wear limit mm (in) 0.2 (0.01)
