BRKT
7-27
69R3J11
Bracket unit
2. Install the tilt lock arm 1 2.
3. Install the tilt lock arm 2 3, rod 4, and
then install the pin 5, cotter pin 6.
4. Install the shallow water lever 7.
5. Install the bolts 8, and then install the
springs 9.
6. Install the rod 4 and 0 to the lever q.
7. Install the pin w, and then insert the cir-
clip e.
8. Install the rod 0, and then install the tilt
lock lever r with spring t.
9. Install the washers y to the through tube
u, and then install them to the swibel
bracket.
10. Set the tilt lock lever r to release posi-
tion, and then install the spring end i.
69R70550
4
5
3
6
69R70555
2
69R70515
8
9
8
7
69R70556
0
q
4
69R70540
w
e
69R70560
t
0
r
69R70570
u
y
69R70580
r
i
69R3J11_07 06.7.5 1:21 PM Page 28
