TIGHTNESS
CANOPY
» The canopy is made of 0,5 mm steel sheet, double
side coated with 185 um of zinc (DX51D AZ185).
» Canopy is assembled of modules equipped
with self-latching grooves securing perfect tightness
of the joints. Modular structure of the canopy
ensures its easy and safe assembly.
ALUMINUM STRUCTURAL POSTS WITH ADDITIONAL SEALING BLADE
AND THERMAL BREAK
» Broken thermal bridge as standard – eliminates humidity condensation on units structural elements.
» Blade along the inspection window ensures labyrinth tightening between panel and AHU body
– currently the most effective solution on the market, mainly applied to laboratory equipment.
» Symmetrical groove in the vertical post’s mounting feet secures its 100% tightness with the AHU casing
structure.
THERMAL
BREAK
ADDITIONAL
POST SEALING
LABIRYNTH
TIGHTNENING
ADDITIONAL
SEALING BLADE
ERGONOMIC INSPECTION PANEL LOCK
» Highly aesthetic and ergonomic handles
securing perfect tightness of inspection panels.
Technical Specification Technical Specification
2524
