CASING
» Panels lled with mineral wool, enclosed with steel sheet on both sides.
» Casing parameters according to EN 1886: T2, TB3, L1, D1, F9.
» Fan and lter section panels tted with hinges.
EC MOTORS
» Efcient, silent and low vibrations fan
with electronically commutated motor
in a IE4 class.
MINI-PLEAT OR BAG FILTERS
Air lters with extended high efciency ltration surface.
» Supply - EU7
» Exhaust - EU5
ENERGY RECOVERY
» Highly efcient counterow
hex recovery with by-pass.
» Recovery efciency reaching 90%.
CONTROLS
» Multifunctional controls, integrated with the
unit – fully pre-congured and ready to run.
DIMENSIONS
» Unit width 88 cm - can be transported through the
opening of 90 cm without disassembling the device.
90 cm
VENTUS COMPACT TOP
FLOOR-MOUNTED UNITS
WITH VERTICAL DUCT CONNECTION
