VTS Ventus VVS650 [36/55] Suspended units
![VTS Ventus VVS021 [36/55] Suspended units](/views2/1894673/page36/bg24.png)
SUSPENDED UNITS
drive efciency
93%
up to
CASING
» Panels lled with mineral wool, enclosed with steel sheet on both sides.
» Casing parameters according to EN 1886: T2, TB3, L1, D1, F9.
CONTROLS
Multifunctional controls, integrated with the unit
– fully pre-congured and ready to run.
MINI-PLEAT FILTERS
Air lters with extended high efciency ltration surface.
» Supply - EU7 (ePM2,5 65%)
» Exhaust - EU5 (ePM10 50%)
ENERGY RECOVERY
» Highly efcient counterow hex
recovery with by-pass.
» Recovery efciency reaching 93%
EC MOTORS
Efcient, silent and low vibrations fan with
electronically commutated motor
in a IE4 class.
VVS005 – VVS650
VENTUS Compact VENTUS Compact
7170
