VTS Ventus VVS650 [37/55] Floor mounted units
![VTS Ventus VVS055 [37/55] Floor mounted units](/views2/1894673/page37/bg25.png)
FLOOR-MOUNTED UNITS
CASING
» Panels lled with mineral wool, closed with steel sheet on both sides.
» Casing parameters according to EN 1886: T2, TB3, L1, D1, F9.
ENERGY RECOVERY
» Highly efcient heat wheel driven by EC motor.
» Recovery efciency reaching 86%
EC MOTORS
Efcient, silent and low vibrations
fan with electronically commutated
motor in a IE4 class.
MINI-PLEAT FILTERS
High performance lters with wide active
ltration cross-section.
» Supply - EU7 (ePM2,5 65%)
» Exhaust - EU5 (ePM10 50%)
CONTROLS
Multifunctional controls, integrated with the unit
– fully pre-congured and ready to run.
ENERGY RECOVERY
» Highly efcient counterow hex
recovery with by-pass.
» Recovery efciency reaching 93%
drive efciency
93%
up to
VVS005 – VVS650
VENTUS Compact VENTUS Compact
7372
