Technical parameters
Accessories
Noise level
* air stream range depends on curtain operation speed

*** speed measurement conditions: semi-open space, horizontal installation on the wall, measurement performed 5 m away from the device
Fan speed
Noise
level
WING W100-200 WING E100-200 WING C100-200
1m 1,5m 2m 1m 1,5m 2m 1m 1,5m 2m
I
dB(A)***
52 53 56 49 51 55 53 54 57
II 55 58 61 51 56 59 59 62 61
III 57 59 62 58 58 60 62 63 63
AHU N° 06.06.320
Range: VENTUS VS 10 - VS 650
AHU N° 06.06.320
Range: VENTUS VS 10 - VS 650
ErP
Ready
Product range
Stream range
WATER HEAT EXCHANGER
HEATING POWER RANGE:
4 – 47 kW
EXHAUST FLOW RAT:
1850-4400 m
3
/h
MAXIMUM AIR COVERAGE:
3,7 m
ELECTRIC HEATER
HEATING POWER RANGE:
2 – 15 kW
EXHAUST FLOW RAT:
1850-4500 m
3
/h
MAXIMUM AIR COVERAGE:
3,7 m
WITHOUT HEAT EXCHANGER
(AMBIENT)
EXHAUST FLOW RATE:
4 m
EXHAUST FLOW RAT:
1950-4600 m
3
/h
210
1066/1582/2098 *
WING 100/150/200
DEDICATED BRACKETS
FASTENING PINS
3000
3700 (4000*)
3000
3000
3700 (4000*)
3700 (4000*)
3000
3700 (4000*) 7400 (8000*)
1000
1,5 m
3000
3700 (4000*)
1,5 m1,5 m
1,5 m1,5 m
1,5 m 1 m 1 m2 m
1 m2 m
3000
3700 (4000*)
3000
3000
3700 (4000*)
3700 (4000*)
3000
3700 (4000*) 7400 (8000*)
1000
1,5 m
3000
3700 (4000*)
1,5 m1,5 m
1,5 m1,5 m
1,5 m 1 m 1 m2 m
1 m2 m
HORIZONTAL
INSTALLATION
VERTICAL
INSTALLATION

*

Vertical air stream range
(maximum installation height)
Horizontal air stream range
(for vertical installation)
* width does not include side covers
9,6 - 11 m/s
*
7 - 9 m/s
*
5 - 7 m/s
*
2,2 m/s*
2,3 m/s*
2,3 m/s*
2,3
2,9
3,7 (4,0**)
5 - 7 m/s
*
2,2 m/s *
7 - 9m/s*
2,3 m/s*
9,6 - 11 m/s *
2,3 m/s*
2,3 2,9 3,7 (4,0**)
Instalations hight [m]
* air stream speed [m/s]
** ambient curtain
air stream range [m]
* air stream speed [m/s]
** ambient curtain
1 SPEED 2 SPEED
3 SPEED
1 SPEED 2 SPEED
3 SPEED
PARAMETERS
WATER AIR CURTAIN ELECTRIC AIR CURTAIN AMBIENT AIR CURTAIN
W100 W150 W200 E100 E150 E200 C100 C150 C200
AC EC AC EC AC EC AC EC AC EC AC EC AC EC AC EC AC EC
Colour
WHITE (RAL 9016) DARK (RAL 7016)
VTS article No.
1-4-2801-0250
1-4-2801-0299
1-4-2801-0259
1-4-2801-0308
1-4-2801-0251
1-4-2801-0300
1-4-2801-0260
1-4-2801-0309
1-4-2801-0252
1-4-2801-0301
1-4-2801-0261
1-4-2801-0310
1-4-2801-0253
1-4-2801-0302
1-4-2801-0262
1-4-2801-0311
1-4-2801-0254
1-4-2801-0303
1-4-2801-0263
1-4-2801-0312
1-4-2801-0255
1-4-2801-0304
1-4-2801-0264
1-4-2801-0313
1-4-2801-0256
1-4-2801-0305
1-4-2801-0265
1-4-2801-0314
1-4-2801-0257
1-4-2801-0306
1-4-2801-0266
1-4-2801-0315
1-4-2801-0258
1-4-2801-0307
1-4-2801-0267
1-4-2801-0316
maximum door width (1 device)
m 1 1,5 2 1 1,5 2 1 1,5 2
maximum door height
(vertical stream range)*
m 3,7 3,7 4
maximum exhaustflow rate
m³/h 1850 3100 4400 1850 3150 4500 1950 3200 4600
heating power range**
kW 4-17 10-32 17-47 2 lub 4/6 8/12 10/15 -
maximum temperature of heating agent
°C 95 - -
maximum operating pressure
MPa 1,6 - -
water volume
dm³ 1,6 2,6 3,6 - -
number of heat exchanger rows
pcs. 2 - -
supply voltage
V/ph/Hz ~ 230/1/50
~230/1/50 for 2kW
~400/3/50 for 4/6kW
~400/3/50 ~230/1/50
electric heating coil power
kW - 2 and 4 4 and 8 5 and 10 -
electric heating coil current draw
A - 6/max.9 11,5/max.17,3 14,5/max.21,4 -
motor power
kW 0,235 0,2 0,375 0,3 0,58 0,47 0,235 0,2 0,375 0,3 0,58 0,47 0,235 0,2 0,375 0,3 0,58 0,47
rated current
A 1,2 1,1 1,7 1,3 2,6 1,9 1,2 1,1 1,7 1,3 2,6 1,9 1,2 1,1 1,7 1,3 2,6 1,9
weight (without water)
kg
20,8   24,5 34,6 30,4 20  26,8 23,4 33,3    23,8 20,4 29,3 
protection rating
IP 20
casing colour
RAL 9016, outlet grid: RAL 9022
HMI WING EC
controller
VTS article No. 1-4-2801-0155
Motor
support
EC
Power supply
voltage
~230V/1ph
/50Hz
Permissible
load
1A for 230VAC
0,02A for 0-10V
Setting range 5…40 °C
Protection
rating
IP 20
Controller
WING EC WIFI
VTS article No. 1-4-2801-0156
Motor
support
EC
Power supply
voltage
~230V/1ph
/50Hz
Permissible
load
1A for 230VAC
0,02A for 0-10V
Setting range 5…40 °C
Protection
rating
IP 20
Valve
with actuator
VTS article No. 1-2-1204-2019
Power supply
voltage
~230V/1ph
/50Hz
Opening 3/3 min
Kvs 4,5
Protection
rating
IP 54
Wall controller
WING/VOLCANO
VTS article No. 1-4-0101-0438
Motor
support
AC
Power supply
voltage
6(3)
V/ph/Hz
Permissible
load
1A for 230VAC
0,02A for 0-10V
Setting range 10...30 °C
Protection
rating
IP 30
Door sensor
(reed switch)*
VTS article No. 1-4-0101-0454
Contact

NO
Switching
current
500 mA
Switching
voltage
max 200 V
Connection screw
Door sensor adapter
WING AC
VTS article No. 1-4-0101-0578
Power
supply
~230V/1ph
/50Hz
Rated imput
power
1W
Protection
rating
IP 55
Dedicated to curtains
with AC motor.
Adapter gives possibilty to use
Door sensor (1-4-0101-0454)
with Wall controller
(1-4-0101-0438).
Flex. connection
hoses (set)
VTS article No. 1-2-2702-0076
Lenght 0,6-0,9 m
Connectrion
type

Max. fluid
pressure
1,6 MPa
Min. working
temperature for
water
5 °C
Min. working
temperature for
glycol
-20 °C
Max. working
temperature
130 °C
Set includes
hose (2 pcs)
gasket (4 pcs)
Wing Wing
103102
