COMPONENTS
Design and application
» Casing structure made of „sandwich”
panels mounted to internal
supporting structure.
» Casing supported on base ralis or
blocks.
» Panel thickness: 40 mm.
» Sheet thickness:
Outer: 0.6 mm, Inner: 0.4 mm
» "Sandwich" double skin panels made
of mineral wool covered on both
sides with sheet metal.
» Indoor and outdoor application.
» Inspection panels mounted on AHU
side.
Specication
» Working temperature: (-40)°C ÷ (+60)°C.
» Panel thickness: 40mm.
» Thermal conductivity PPU
λ= 0,039 W/mK.
» Casing re resistance: A1 (EN
13162:2012 + A1:2015 (EN 13501-1)
» Moisture absorption:
- short term: WS, Wp: ≤ 1 kg/m²
(EN 13162:2012 + A1:2015 (EN 1609)
- long term: WL(P), Wlp: ≤ 3 kg/m² (EN
13162:2012 + A1:2015 (EN 12087)
» PPU density: ρ= 80kg/m³.
» Corrosion protection: - Exterior:
AZ150 (Aluzinc) coating, Coating
thickness> = 150 g / m² with an
additional organic coating.- Inside
side: Coating Z140 (zinc), Coating
thickness> = 140 g / m²
» Certied by Eurovent
CASING > FLOOR MOUNTED COMPACT UNITS
Design and application
» Mini-pleat lters are special type
of panel lters. They are design to
provide many times larger active
ltration surface followed by higher
dust-holding capacity than typical
panel ones, at the same outer lter
cartridge dimensions. Filters consist
of ultra-thin microbers, coated with
special, condensed binder. Mini-pleat
are characterized by much longer
life span the typical, commonly used
ones.
» Applied as initial or secondary stage
of air ltration.
Specication
» Max working temperature:
(+70)°C, 100% RH.i.
Available ltration classes
» ISO ePM10 50% (ISO 16890)
- M5 (EN779),
» ISO ePM2,5 65% (ISO 16890)
- F7 (EN779),
» ISO ePM1 70% (ISO 16890)
- F9 (EN779)."
MINI PLEAT FILTERS
Design and application
» Casing structure made of „sandwich”
panels mounted to internal
supporting structure.
» Panel thickness: 40 mm.
» Sheet thickness: Outer: 0.6 mm,
Inner: 0.4 mm
» "Sandwich" double skin panels made
of mineral wool covered on both
sides with sheet metal.
» Indoor application
» Inspection panels mounted on top
and bottom of the unit (maintenance
from bottom).
» Casing designed to be suspended
above false ceilings, equipped with
elements facilitating its installation.
Specication
» Working temperature: (-40)°C ÷ (+60)°C.
» Panel thickness: 40mm.
» Thermal conductivity PPU
λ= 0,039 W/mK.
» Casing re resistance: A1 (EN
13162:2012 + A1:2015 (EN 13501-1)
» Moisture absorption:
- short term: WS, Wp: ≤ 1 kg/m²
(EN 13162:2012 + A1:2015 (EN 1609)
- long term: WL(P), Wlp: ≤ 3 kg/m² (EN
13162:2012 + A1:2015 (EN 12087)
» PPU density: ρ= 80kg/m³.
» Corrosion protection:
- Exterior: AZ150 (Aluzinc) coating,
Coating thickness> = 150 g / m² with
an additional organic coating.
- Inside side: Coating Z140 (zinc),
Coating thickness> = 140 g / m²
» Certied by Eurovent
CASING > SUSPENDED COMPACT UNITS
Design and application
» Single inlet, radial, backward curved,
free running fan.
» Impeller made of SAN (styrene/
acrylonitryle) construction material
with 20% glass ber.
» Direct drive – fan impeller installed
directly on motor shaft.
» Fan section consisting of single
or multiple fans (fan array) in
order to ensure optimum working
parameters.
Specication
» Low and medium pressure
ventilation systems with fan static
pressure not exceeding
2000 Pascals.
» Maximum fan set working
temperature: 60°C.
DIRECT DRIVE PLUG FAN SET
» Set of fan and motor mounted on
common rail, xed to the AHU fan
diaphragm.
» EC motors are Permanent Magnet
motor, characterised by much higher
efciency vs traditional inductive AC
motors.
» EC motors (Electronically
Commutated) – where mechanical
commutator switching the windings
has been replaced with electronic
one.
» Change of revolutions is done by
means of changing the frequency
rate of windings switching (rate or
magnetic eld rotating).
» Highly inductive permanent magnets
have applied in EC motors used by
VTS, which enabled to achieve high
torque at relatively small dimensions,
together with reaching IE4 efciency
class.
» Available Energy classes: IE4.
» Rated voltage: EC motors of nominal
capacity exceeding 0,75kW -
3x400V AC.
» Rated voltage: EC motors of nominal
capacity equal or less 0,75kW -
1x230V AC.
» Motor widing insulation class: F.
» Protection degree: IP54.
» Maximum working ambient
temperature: 55°C.
» Lifespan:
- 70 000 hours at load not exceeding
70% of nominal capacity at ambient
temperature not exceeding 35°C,
- 30 000 hours at 100% capacity
load at ambient temperature not
exceeding 55°C.
> EC MOTORS
