VTS Ventus VVS650 [32/55] Suspended units floor mounted units
![VTS Ventus VVS400 [32/55] Suspended units floor mounted units](/views2/1894673/page32/bg20.png)
HIGHLY EFFICIENT
HEX COUNTER-FLOW
HEAT RECOVERY
ENERGY SAVING
AND SILENT FANS WITH
EC MOTORS
PLUG&PLAY
PRODUCT
INTEGRATED
MULTIFUNCTIONAL
CONTROLS
HIGHLY EFFICIENT ROTARY
AND HEX COUNTER-FLOW
HEAT EXCHANGER
ENERGY SAVING
AND SILENT FANS WITH
EC MOTORS
PLUG&PLAY
PRODUCT
INTEGRATED
MULTIFUNCTIONAL
CONTROLS
recovery efciency
90%
up to
recovery efciency
90%
up to
recovery efciency
90%
up to
MINERAL WOOL
INSULATION
MINERAL WOOL
INSULATION
VENTUS Compact TOP
with hex counter-ow
heat exchanger
VENTUS Compact
with rotary heat exchanger
or hex counter-ow heat exchanger
max. 490 mm
> VENTUS Compact
0,5L
> Standard Air Handling Units
1L
7 500 m³/h7 500 m³/h
max. 880 mm
max. 2940 mm
SUSPENDED UNITS FLOOR-MOUNTED UNITS
VENTUS Compact VENTUS Compact
6362
