Secure Device Server User Manual

4. Align the device and mounting plate assembly to one of the slots on the

VE-RMK1U frame, and then secure the mounting plate to the frame with

the plastic captive screw provided.

Note: Up to 4 Secure Device Servers can be secured onto a VE-RMK1U frame.

VE-RMK1U Frame

slot 1

slot 2

slot 3

slot 4
