Toggle the switch up or down to raise or lower the landing gear.

6. Battery Level LEDs

Displays the current battery level.

7. Status LED

Displays the power status.

8. Power Button

Used to power on or power off the remote controller.

9. RTH LED

Circular LED around the RTH button to display RTH status.

Remote Controller Top View

Figure 22

10. Camera Settings Dial

15. Gimbal Dial

11. Playback Button

16. HDMI Port

12. Shutter Button

17. Micro-USB Port

13. Flight Mode Switch

18. CAN Port
