©2014 DJI All Rights Reserved 16 |
14. Video Recording Button
19. USB Port
10. Camera Settings Dial
Turn the dial to adjust camera settings. Only functions when the remote controller is connected to a mobile
device running the DJI Inspire 1 app.
11. Playback Button
Playback the image or the videos.
12. Shutter Button
Press to take a photo. If in burst mode, the set number of photos will be taken with one press.
13. Flight Mode Switch
Used to switch between GPS, A and F mode.
14. Video Recording Button
Press to start recording video. Press again to stop recording.
15. Gimbal Dial
Use this dial to control the tilt of the gimbal.
16. Micro-USB Port
Connect remote control with your computer.
17. HDMI Port
Connect an HD compatible monitor to this port to get a live HD video preview of what the camera sees.
18. CAN port
Reserved for future use.
19. USB Port
Connect to mobile device to access all of the DJI Inspire 1 app controls and features.
