5•1
How To...
Relay G70/G75 Advanced Guide
How To...
This Chapter provides instructions for conguring your Line 6 Relay
®
Receiver & Transmitter,
as well as several tips and feature descriptions to help you get the most out of your new
wireless system.
About Scenes
First, it is important to understand the concept of “Scenes,” as used in your Relay wireless
system... As mentioned in the “Quick Start” chapter, your Relay Receiver & Transmitter
are congured with factory default settings allowing them to work together right out of the
box (both set to Channel 1). But we’ve oered quite a bit more exibility, where you can
customize several settings and save them all in a preset, which we refer to as a “Scene.” By
creating several Scenes on your Receiver, it is then possible to instantly recall these settings
with the “stomp” of a switch, allowing you to easily change to a dierent instrument and/or
Transmitter, route your instrument signal to dierent destinations, and recall dierent Gain
and Cable Tone settings. The following sections cover all the details for creating and working
with Scenes, so read on to start personalizing your Relay to best suit your performance
needs.
Edit Mode
To modify individual parameters for your current Scene, you will need to enter Edit Mode.
Also note that, while in Edit Mode, pressing the Select/Mute footswitch (G70) or button
(G75) cycles through your saved Scenes, providing edit access to other Scenes’ parameters
without having to return to the Home screen just to get to the settings of another Scene.
2
Off
2
CableTone
Channel
Rename? SCENE2
Parameter Name
Up to 3 parameters visible
at a time - scroll to access
all
Value
(Functional parameters
display no value here)
Scroll Bar
Indicates vertical menu
list position
Input Icon
Wireless icon shown when signal
present
(AUX input displays an input jack)
Edit Mode - Editing a parameter
Editing Scene Parameters
• Press the EDIT button to enter Edit Mode.
• Once in the Edit Mode screen, turn the Nav/Select Encoder knob to highlight the
parameter you wish to edit.
• Push the Encoder to access the options for the selected parameter.
• Turn the Encoder to the desired value.
• Push the Encoder again to accept the displayed value - or, if you want to cancel the
change, press the EDIT button.
