A•2

Appendix: Product SpecicationsRelay G70/G75 Advanced Guide

Relay G70 & G75 Receiver Specications

RELAY G70/G75 - SPECIFICATIONS

System Lock Time < 1 second

Audio Frequency Response 10-20kHz, +1dB / -3dB

Dynamic Range > 120 dB A weighted

Range > 60 meters (200 feet)*

Receiver Gain 0 dB nominal, variable -18 to +12dB per user setting

Aux Input Maximum Level Before Distortion 5.5Vpp

Aux Input Impedance 1.3MΩ

Output Impedance Outputs A and B: 100Ω

Output C (XLR): 300Ω

Aux Input to Output SNR > 120dB

USB Type Micro USB 2

Power Requirements USB: 3Watts (585mA)

9VDC (center negative): 3Watts (350mA)

*Line of sight. Actual range depends on environmental factors such as RF interference, RF reections and

RF absorption.
