5•2
How To...
Relay G70/G75 Advanced Guide
• Select the next parameter within the Scene to edit and repeat.
• When nished, press the HOME button to exit Edit Mode - your changes are
automatically saved in the Scene.
Tip! Note that while in Edit Mode, you can press Select/Mute at any point to edit another Scene, rather
than having to exit to the Home screen.
When highlighting each parameter in Edit Mode, note that the symbol at the left of the screen
changes to indicate the parameter type:
• The Channel number or Aux Input symbol is displayed, indicating the setting is
applied only for the current Input, and only for the current Scene.
• The “add” symbol indicates that a new Scene will be created.
• The “gear” symbol indicates a global setting, meaning it aects all Scenes and
Inputs.
Editable Parameters
TYPE PARAMETER VALUES DEFAULT VALUE
Per Scene
Ch. 1-16 or
Aux In
Rename? Up to 8 characters “SCENE1” initially -
Automatically defaults
to the name of the
Scene in use when Edit
Mode was entered
Channel 1 - 16, AUX, SCAN 1
Cable Tone (in feet) O, 3’, 5’, 10’, 15’, 20’, 25’, 30’,
40’, 50’, 60’, 70’, 80’, 90’, 100’
O
Cable Tone (metric) O, 1, 1.5, 3, 5, 6, 8, 9, 12, 15, 18,
21, 24, 27, 30 Meters
O
Output A, B, C, A+B, A+C, B+C, A+B+C,
Mute All (Tuner Out is always on)
A+C
Gain -18dB to +12dB with 1dB
resolution
0dB (unity gain)
Scene Select Switch Color Green, Blue, Orange, Purple,
Aqua, White
Green
Remove (Scene Name)?
Cancel, OK Cancel
Add
Add Scene CH. 1 - CH. 16, AUX, AUTO New Scenes default to
the Channel assigned to
the Scene in use when
Edit Mode was entered
Global
LCD Brightness Low, High High
Aux In Always On, Scene Only Always On
Info? Lists rmware version for Receiver (and Transmitter, if in use)
Factory Reset? Cancel, OK Cancel
