5•7
How To...
Relay G70/G75 Advanced Guide
• If manually selecting a Channel or AUX Input: Press the Nav/Select Encoder to
commit your selection.
High
CH.2
LCD Brightness
Add Scene
Remove SCENE2?
High
CH.3
LCD Brightness
Add Scene
Remove SCENE2?
Edit Mode - Adding a Scene: manually selecting a Channel
Note: If you are using one single Transmitter, it is typically best to keep the Channel number for all Scenes
set to the same Channel as set on your Transmitter.
Adjusting the Receiver’s LCD Screen Brightness
If you are having trouble reading the LCD screen on your Relay Receiver, try adjusting the
brightness as shown below. Note that this is a “global” option and, therefore, aects the
display regardless of what screen is shown.
• While in Edit Mode, select “LCD Brightness” and press the Nav/Select Encoder.
• Turn the Encoder knob to choose the desired brightness level.
• Press the Nav/Select Encoder to commit your selection.
High
CH.2
LCD Brightness
Add Scene
Remove SCENE2?
Edit Mode - Adjusting the LCD Brightness global parameter
Conguring the Aux Input
This section determines the behavior of the Aux In jack. Note that this is a global setting and,
therefore, aects the Aux In behavior in all Scenes. Congure this option as follows:
• While in Edit Mode, select “Aux In” and press the Nav/Select Encoder.
• Turn the Encoder knob to choose the desired mode:
• Always On - You’ll hear the Aux In signal if no Transmitter is detected or if the
Scene‘s Edit Mode - Channel option is set to AUX. This can be very handy if you
forget, or decide not to use, Transmitters for a gig. All the programmed routing in
every scene will just use the Aux In instead.
• Scene Only - You’ll only hear the Aux In signal if the Scene‘s Edit Mode - Channel
option is set to AUX. If the Transmitter is O, you will only hear a signal from the
Aux In if you have congured the Scene’s Channel option to use the Aux In.
• Press the Nav/Select Encoder to commit your selection.
Aux In Always On
Factory Reset
Info?
Edit Mode - Conguring the Aux In global parameter
