A•1
Appendix: Product SpecicationsRelay G70/G75 Advanced Guide
appendix: produCT speCifiCaTions
Provided here are the Product Specications for the Line 6 Relay
®
G70 & G75 System,
Receiver and TB516 G Transmitter devices for your reference.
Relay G70 & G75 System Specications
RELAY G70/G75 - SYSTEM SPECIFICATIONS
Transmission Type Digital
Operation Radio Band 2.4GHz ISM
Radio Mode Frequency Hopping
Latency - Tx Input to Rx Output < 1.5ms
System Lock Time < 1 second
Audio Frequency Response 10Hz – 20kHz, ± 1dB
Dynamic Range >120dB
THD + Noise < 0.04% (1kHz @ -10dBFS)
System Gain 0 dB nominal, variable -18dB to +12dB per user setting
System Polarity +Voltage applied to tip of TB516 G Guitar input produces
positive voltage on A, B, and C outputs of Receivers
Working Range 60 meters (200 feet)*
Available Channels 16
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -10°C to 50°C (14°F to 122°F)
*Line of sight. Actual range depends on environmental factors such as RF interference, RF reections and
RF absorption
Relay TB516 G Transmitter Specications
RELAY TB516 G - TRANSMITTER SPECIFICATIONS
Transmitter Input ¼ Inch Phone Plug, Tip-Sleeve
Operational Radio Band 2.4GHz ISM
Input Impedance 1MΩ
RF Output Power 10mW E.I.R.P. Max
Maximum Input Level Before
Distortion
5.5Vpp
Battery Life > 8 Hours w/ 2x AA Alkaline
Standby Time > 60 Hours (2x AA Alkaline in Sleep Mode)
Available Channels 16
