5•6
How To...
Relay G70/G75 Advanced Guide
Removing a Scene
It is possible to delete previously-created Scenes, with the exception that one Scene must
always remain on the Receiver. To remove a Scene:
• Press the Select/Mute footswitch (G70) or button (G75) to navigate to the Scene you
wish to delete.
• Enter Edit Mode and rotate the Nav/Select Encoder to select Remove XXXXX
(where “XXXXX” is the name of the Scene you selected in the rst step).
• If you are sure this is the Scene you wish to delete, turn the Encoder to select OK,
otherwise leave Cancel highlighted.
• Press the Encoder to commit your selection.
2
High
CH.2
LCD Brightness
Add Scene
Remove
SCENE2?
2
OK
Cancel
Remove
SCENE2?
-
SCENE2 Removed!
Edit Mode - Removing a Scene
Adding a Scene
There are dierent reasons for why you may want to create additional Scenes on your
Receiver, such as:
• To store dierent parameter settings (Gain, Cable Tone, Switch Color, etc.) that
might work better when you move your Transmitter to a dierent instrument.
• To create a Scene that utilizes only the Aux Input of your Receiver.
• To create a Scene with all Outputs muted, so you can safely unplug cable connections
during a gig.
• To add one or more additional Transmitters for use with your Relay Receiver, where
each Scene can be set to use a specic Transmitter/Channel.
Below are the basic steps for how to create a new Scene. It is also recommended that you
read through “Adding Additional Transmitters to your Receiver” on page 5•9 to gain a
deeper understanding of the use of multiple Transmitters in your setup.
• While in Edit Mode, select “Add Scene” and press the Nav/Select Encoder.
• Turn the Encoder knob to choose the desired Channel 1-16, select AUX (to receive
only the Receiver’s Aux Input signal) or choose AUTO to have the Receiver run its
Auto Scan for unused Channels.
• If using AUTO Scan: Be sure to power your Transmitter O, then press the Nav/
Select Encoder and follow the screen prompts for conguring your Transmitter to
the recommended Channel.
High
CH.2
LCD Brightness
Add Scene
Remove SCENE2?
High
CH.AUTO
LCD Brightness
Add Scene
Remove SCENE2?
Edit Mode - Adding a Scene: using Auto Scan
