LINE 6 Relay G75 [21/40] Checking the info details for your receiver and transmitters
![LINE 6 Relay TB516G [21/40] Checking the info details for your receiver and transmitters](/views2/1992380/page21/bg15.png)
5•8
How To...
Relay G70/G75 Advanced Guide
Checking the Info Details for your Receiver and Transmitters
The Edit Mode - Info option displays the current rmware versions for your Receiver, as well
as for Transmitters that you currently have in use.
• While in Edit Mode, select “Info” and press the Nav/Select Encoder. The display will
show the Firmware version for the Receiver.
Aux In Always On
Factory Reset
Info?
G75 Ver. 1.01
Close
Edit Mode - Info screens showing Receiver’s Firmware version
• If a Transmitter is synced to the Receiver, the Next menu will appear. Select Next to
display the Transmitter’s Firmware version, or Close to exit.
• Transmitter Info will only be displayed for the Transmitter actively in use for the
current Scene.
• To check Info on a Transmitter that is currently active on another Channel, select a
Scene with the desired Transmitter assigned to it, and repeat the steps above.
TB516 G Ver. 1.01
Close Back>
G75 Ver. 1.01
Close
Next>
2
Edit Mode - additional Info screens showing the assigned Transmitter’s Firmware version
Performing a Factory Reset
Should you ever need to completely restore your G70/G75 Receiver back to the original
factory settings, you can use the Factory Reset option.
Note that this action will permanently erase all Scenes and Transmitter pairings,
and set all parameters back to their default settings.
To perform a Factory Reset:
• From the Edit Menu, select “Factory Reset?“ and press the Nav/Select Encoder.
• Turn the Encoder to select OK if you wish to proceed with the reset, or Cancel to exit.
• Press the Encoder button to commit your selection.
Aux In Always On
Factory
Reset
Info?
Factory Reset-Sure?
Cancel
OK
Complete!
Edit Mode - Factory Reset
