A•4
Appendix: Product SpecicationsRelay G70/G75 Advanced Guide
Relay G75 Receiver Dimensions
2.63”
66.75mm
.85”
21.50mm
6.22”
/
158mm
4.65”
118.06mm
.78”
19.85mm
1.71”
/
43.35mm
2.89”
/
73.35mm
3.73”
/
94.85mm
4.58”
/
116.35mm
.60”
15.15mm
