6•6
Tip for Best Operation & Hook Up Examples
Relay G70/G75 Advanced Guide
G70 Acoustic Guitar Direct to PA + Powered Monitor Hook Up
OR
Out A
Out C (XLR)
Front of House / PA
Monitor
5V USB
Scene1
Scene2
Relay G75
G70 Electric and Acoustic Guitar to Two Amps + PA Hook Up
OR
Amp / FX (A) Amp / FX (B)
Front of House / PA
Tuner
Tuner
Out
Out B
Out A
Out C
5V USB
Scene1
Scene2
Scene3
NAVEDIT
SELECT / MUTE
P
U
S
H
T
O
S
E
T
