5•14
How To...
Relay G70/G75 Advanced Guide
Using Standard Guitar Cables
Regular 1/4” to 1/4” TS guitar cables work perfectly well with the Relay TB516 G Transmitter,
with the exception that the locking feature is not supported.
Transmitter User Interface
The Relay TB516 G Transmitter is designed for fast, simple setup, with the live and studio
performer in mind.
On/O - Turns power On when working batteries are installed. The Transmitter will
automatically sync with the Receiver in less than 1 second, so there is no need for a
separate mute function on the Transmitter itself.
Channel Select - Press the p Up or q Down button next to the Channel Display once
to light the Channel number indicator (see the Channel Display info on page 3•2). The
current Channel is indicated by the dual 7-segment displays next to the Up and Down
buttons. Press either Up or Down to change the Transmitter Channel. The Channel number
will ash for 2 seconds* after the Channel is selected indicating the change has been
executed.
*Note: The transmission Channel does not immediately change while selecting the Up and Down buttons,
allowing you to navigate to the desired, available Channel without conicting with other active Transmitters.
Auto-Sleep Switch - Enables/disables internal circuitry used to determine if the Transmitter
is idle (i.e. - when no movement and no audio is detected from the Transmitter). Place the
switch in the position to enable this feature (see the Auto-Sleep Switch info on page
3•2).
When Auto-Sleep is enabled, the Transmitter will automatically go into a low power/idle
mode after two minutes pass without any movement or audio detected. This functionality
allows you to simply turn down your instrument’s volume knob and place the instrument in
a stand during set breaks to minimize battery drain without having to power the Transmitter
O. While in idle mode, the Transmitter will check every 500ms for motion in order to turn
back On. The Transmitter will be synced and ready to transmit no more than 2 seconds
after detecting motion or audio at its input.
