LINE 6 Relay G75 [28/40] Batteries for your transmitter
![LINE 6 Relay G70 [28/40] Batteries for your transmitter](/views2/1992380/page28/bg1c.png)
5•15
How To...
Relay G70/G75 Advanced Guide
Batteries for your Transmitter
The Relay TB516 G requires two AA batteries for proper operation (also see the Battery
Compartment info on page 3•2). Any battery type’s dimensions that comply with ANSI
C18.1M. Part 1-2001 will physically t. Not all batteries comply with published standards,
so it is a good idea to verify t and compliance prior to purchase. Most higher quality AA
batteries will t ne.
A Few Tips on Battery Use...
• Always use name brand batteries that you trust.
• Lithium batteries will provide the longest possible run time, but they are more
expensive than alkalines.
• Most pro users always use fresh batteries for each performance and keep the show-
used batteries for rehearsals, where it may be okay to use them until they run all the
way down.
• Rechargeable batteries are a great way to save money and provide a convenient
power source for your Transmitter. Some rechargeable batteries expand and contract
in size depending on the charge level. It is important to check the t or ask the
manufacturer of rechargeable batteries if they comply with ANSI standards when fully
charged.
Battery Status Light
The Battery Status LED at the top of the Transmitter (also see page 3•1) illuminates solidly
green when the Transmitter is powered On and when more than 1 hour of battery operation
time remains. It ashes yellow when less than 1 hour and ashes red when less than 30
minutes of battery operation time remain. The Receiver Home screen also displays remaining
battery time for the Transmitter in use with the current Scene - see “The Home Screen” on
page 4•3.
Note: Battery operation time is calibrated for 2x AA Alkaline batteries - actual times may vary when using
non-alkaline batteries.
Installing Firmware Updates
The Relay G70 & G75 Receiver and TB516 G Transmitter hardware incorporate updatable
Firmware. It is highly recommended to periodically check for and install the latest Firmware
updates to keep your gear operating at its best. Firmware updates are easy to perform by
using the free Line 6 Updater Utility software.
Please visit line6.com/software to download the Line 6 Updater Utility for your Mac
®
or
Windows
®
computer, then install the application. To follow are the steps for updating your
Relay hardware - the steps are similar for the G70 & G75 Receiver as well as for the TB516 G
Transmitter:*
*Line 6 recommends removing the batteries from the TB516 G Transmitter when updating Firmware.
