LINE 6 Relay G75 [22/40] Adding transmitters using the auto scan method
![LINE 6 Relay TB516G [22/40] Adding transmitters using the auto scan method](/views2/1992380/page22/bg16.png)
5•9
How To...
Relay G70/G75 Advanced Guide
Adding Additional Transmitters to your Receiver
The G70/G75 Receivers provide the ability to switch between multiple Transmitters at
the push of a switch. This allows you to set up several instruments each with their own
dedicated Transmitter, and then switch instruments quickly and safely without having to
worry about turning a Transmitter On and O and moving it to a dierent instrument during
your performance.
Adding an additional Transmitter is achieved by creating a new Scene and conguring a
unique Channel to communicate with the new Transmitter. The G70/G75 Receivers oer two
methods for adding a Transmitter: using Auto Scan or manually.
Adding Transmitters Using the Auto Scan Method
• Press the EDIT button on your Receiver to enter Edit Mode.
• Turn the Nav/Select Encoder knob and select “Add Scene“ from the menu - press
the Encoder knob.
High
CH.2
LCD Brightness
Add Scene
Remove SCENE2?
High
CH.AUTO
LCD Brightness
Add Scene
Remove SCENE2?
• Rotate the Encoder until CH. AUTO appears - press the Encoder knob.
High
CH.2
LCD Brightness
Add Scene
Remove SCENE2?
High
CH.AUTO
LCD Brightness
Add Scene
Remove SCENE2?
• The display will instruct you to turn your new Transmitter O so it can do a clean scan.
Note that you should leave any existing Transmitter that you already have congured
with the Receiver powered On, and Auto-Sleep mode turned O - this way the Auto
Scan will detect it and choose an unused Channel for the new Transmitter you are
adding.
Make sure new Tx is
powered off...
Next>
• When the new Transmitter’s power is O, select NEXT and press the Encoder.
• The Receiver will scan the spectrum, recommend a clean Channel, then prompt
you to turn On the new Transmitter and set its Channel. (For details on setting the
Transmitter’s Channel, see page 3•2.)
Next>
Turn
on new Tx and
set to channel 13...
High
CH.AUTO
LCD Brightness
Add Scene
Remove SCENE2?
Next>
Make
sure new Tx is
powered off...
Scanning...
• Select Next - the screen will conrm that the Transmitter was found and inform you
what Switch Color was set. You can change the Switch Color for the Scene later if
desired - see “Changing the Switch Color Ring” on page 5•5.
OKCancel
TX
13 Found!
Switch Color Green
