Appendix B: FBV Foot Controllers

B•16

EXP 1 and EXP 2 with Pedal 2 Connected

Whena2ndExpressionPedal(suchasaLine6EX-1ExpressionPedal)isconnectedto

FBV Shortboard, the on-board Pedal remains mapped to only EXP 1, and Pedal 2 to only

EXP 2. Whenever a Pedal 2 is connected, you’ll see the EXP 1 & EXP 2 LEDs both lit.

Expression Pedal Assignment

As shown in the preceding tables, FBV devices’ Pedals are designed to access the POD HD

EXP 1 and EXP 2 controllers, which can be assigned to virtually any Amp or FX Model

parameter. To follow are the steps to assign these controllers to POD HD parameters.

Controlling Amp & FX Parameters

Conﬁguring the EXP 1 & EXP 2 assignments is done within the Controller Assign screen.

These settings are all saved per Preset. From the Signal Flow View screen, select the Amp

or FX Block for which you’d like to create a Pedal assignment, then double-press the

MOVE button. For our example, we’ll select our Delay FX block in the Signal Flow View:

ENTER

DBL PRESS TO ASSIGN CTL

MOVE

AMP & FX ON / OFF

Note: When a Controller is assigned to any FX Model parameter, manually editing this

parameter’s value will result in changing the Controller’s MIN or MAX value. For example,

if the EXP-1 Pedal Controller is assigned to a Wah FX Model’s Position parameter, select

the Wah Model, go to its Edit View screen, and select the Position parameter. If you turn

multifunction knob #4 when the Pedal is near the “heel” position, the MIN value is

adjusted. If you turn the knob when the Pedal is near the “Toe” position, the MAX value

is adjusted.
