LINE 6 POD HD Desktop [16/113] About source input signal routing
![LINE 6 POD HD Desktop [16/113] About source input signal routing](/views2/2009085/page16/bg10.png)
System Setup
2•6
Amp & FX Model - Guitar Input Impedance Ratings
Model Guitar Input Impedance
(Ohms)
Filter FX
All Filter Models 1M
Pitch FX
All Pitch Models 1M
Delay FX
Multi Head 22k
Analog Echo 230k
Analog w/Mod 90k
All Other Delay Models 1M
Preamp + EQ FX
All Preamp & EQ Models 1M
Reverb FX
All Reverb Models 1M
Wah FX
Weeper 90k
All Other Wah Models 1M
Volume & Pan FX
All Volume and Pan Models 1M
FX Loop
FX Loop 1M
About Source Input Signal Routing
ItisimportanttonotehowPODHDactuallyroutesSourceInputs1and2throughAmp
& FX Blocks that are positioned “Pre” position. The following behaviors apply:
• In a configuration with no Amp or FX Blocks in Pre, Input 1 is fed only to Path A
andInput2onlytoPathB.Therefore,thisisthebestcongurationifyouwantto
retain discrete Input Sources into Paths A & B.
