FX Models
7•1
FX mOdelS
POD® HD includes a plethora of amazing FX Models, primarily from the popular Line 6
M13 Stompbox Modeler! This chapter provides Reference Tables showing all POD HD
FX Models by category, as well as details on their parameters. FX Model parameters are all
accessible within the Edit Mode. Please see “FX Edit Mode” on page 5•1 for details on
Edit Mode features.
TIP: For more details about the POD HD FX Models, please also check out the POD HD
Model Gallery
and M13 Advanced Guide documents, available from http://line6.com/
support/manuals/
.
Dynamics Models
Dynamics FX Models - Parameter Reference Table
Model Parameters
Hard Gate Open Threshold Close Threshold Hold Decay --
Noise Gate Threshold Decay -- -- --
Tube Comp Threshold Level -- -- --
Red Comp Sustain Level -- -- --
Blue Comp Sustain Level -- -- --
Blue Comp Treb Sustain Level -- -- --
Vetta Comp Sensitivity Level -- -- --
Vetta Juice Amount Level -- -- --
Boost Comp Drive Bass Comp Treble
Output
Common Parameters
The following parameters are common to most Dynamics FX Models.
• Threshold: For compressor FX, lower values result in greater compression, along
with an automatic makeup gain stage dependent upon the Threshold setting.
• Sustain: Some compressors include Sustain, which is much the same as a Threshold
control, but functions in reverse - higher settings add more compression and thus
more sustain and squishy goodness.
• Level: Adjusts the overall volume - higher settings typically offer an output boost.
