Appendix B: FBV Foot Controllers

B•20

Using the EXP Pedal Toe Switch

As noted above, when adding a Wah or Volume/Pan Model to your tone, their Position

parameters are automatically assigned to the EXP 1 and EXP 2 controllers. Most Factory

Presets already include this Wah/Volume switching pre-conﬁgured for you. But the Toe

Switch assignment is not set automatically for newly added Amp or FX Models, so here is

how to set this up manually.

• With the Wah Model selected, go to the FS Assign screen and assign its FX Block to

the EXP TOE SWITCH, following the instructions above. This allows the Wah to

be toggled On/Off via the pedal Toe Switch.

Assigning an FX Block to the on-board pedal’s “Toe Switch”

Further, if you have a different FX parameter (such as the Volume - Position) being

controlled by the opposite EXP Pedal Mode, you’ll likely ﬁnd it useful to have the Toe

Switch toggle both these FX Blocks On/Off alternately, so that only the desired Model

is active while being controlled. For example, say you have a Preset where the Wah is

controlled by EXP 1, and the Volume by EXP 2:

Note: If you have a “Pedal 2” connected to your FBV (or if using an FBV Longboard) you

may not want to use the following conﬁguration, since the Wah and Volume are already

controlled by your two Pedals individually.

• Click the EXP TOE SWITCH switch so that the red EXP 1 LED is lit.

• In the Signal Flow View, select the Volume FX block and toggle it “Off” using the

ENTER button. You should now see the Wah “On” and the Volume “Off.”
