LINE 6 POD HD Desktop [79/113] Inputs recording page

USB Audio

9•5

Inputs & Recording Page

The Line 6 Audio-MIDI Settings window - Inputs & Recording page

Record Sends List: Displayed here are the Record Sends for the current Line 6 device

that will be available to your audio software. For POD HD you’ll see the one, stereo “1-2

Main Out” Record Send.

Hardware Monitor Level: This slider independently controls the volume of your

processed guitar tone output for monitoring (the signal fed to the device’s main outputs).

It does not affect the level of the signal fed to your computer via the Record Send. This

allows you to balance your guitar’s monitor level against the playback audio from your

computer, such as when recording in DAW software.

If using POD HD as the audio interface for recording into a DAW application, then

your DAW may also offer its own “software monitoring” function. You may want to

use the DAW’s software monitoring in some scenarios, such as if you want to hear your

guitar signal processed with plug-ins on the DAW track. When utilizing DAW software

monitoring, you’ll want to set this slider’s level to minimum to allow you to hear only the

DAW software monitoring signal.
